Title: 130T Hydraulic cap injection machine for water production line
Key words: cap injection machine, cap injection molding machine, cap injection equipment
Model: ZS-130
Brand: FILL-PACK
Power: 23kw
Voltage: 380V 3PH 50HZ or customized
Driven force type: pneumatic
Automation degree: Automatic
Application: cap injection
Condition: New
PROPERTIES:
Capacity: 130Ton
Key material: cast iron
Fuction: cap injection
Processing material: PET
Cap weight: 0-5g
Clamp ton: 130
Injection store: 200mm
Injection weight: 230g
Injection pressure: 16Mpa
Origin: ZhangJiaGang, China
After sales service: Engineers avaliable to service overseas
Qualification: CE, ISO9001-2008
| Subject | Unit | ZS-130 | ||
Injection | Screw Diameter | Mm | 36 | 40 | 45 |
Theoretical injection pressure | MPa | 248 | 201 | 159 | |
Theoretical shot Volume | cm3 | 204 | 251 | 318 | |
Injection Weight | g | 187 | 231 | 293 | |
Injection Rate | g/s | 93 | 114 | 137 | |
Max Screw Speed | rpm | 213 | |||
Injection stroke | mm | 200 | |||
Clamping | Clamp tonnage | TON | 130 | ||
Toggle stroke | mm | 370 | |||
Space between tie bars | mm*mm | 425*425 | |||
Ejector Pin | Unit | 5 | |||
Ejector Stroke | mm | 130 | |||
Others | System pressure | Mpa | 16 | ||
Pump motor Power | KW | 13 | |||
Heater Power | KW | 10 | |||
Machine Dimension (l*w*h) | m | 4.97*1.26*1.95 | |||
Oil tank capacity | L | 280 | |||
Machine weight | T | 4.2 | |||
1, Sea shipping worthy packing for cap injection machine
2, Moulds with rust-proof treatment
1, Pre-quotation communication to know customers’ excat requirement and give proper suggested frame;
2, Quotation offer as in advance communications;
3, Quotation explanations given if necessary;
4, Plant design and bottle-cap-label searching & design if needed after offer confirmed;
5, Contract signing basing on all discussed;
6, Production as contract items;
7, Inspection and delivery done as contract standard;
8, Technician service overseas as contarct agreed;
9, Whole life after sales service for spare parts;
