Carton Packing Machine-3

Title: Munual folding case sealer to suit different case sizes

Key words: case sealer, case sealing machine, carton sealer

Inquire Now

Quick Details
Detailed Descriptions
Packaging & Delivery
Services

QUICK DETAILS:

Model: FXJ-6050B

Brand: FILL-PACK

Power: 180W

Voltage: 380V 3PH 50HZ or customized

Driven force type: Electrical

Automation degree: Automatic

Dimension: 960*850*1270mm

Weight: 180KG

Application: carton case sealing

Packing category: case

Packing material: paper

Condition: New

PROPERTIES:

Capacity: 0-6 packs per minute

Applicable pack pattern: 2*3 or 4*6 or 3*4

Key material: carbon steel

Fuction: case sealing

Max wrappage: as required

Origin: ZhangJiaGang, China

After sales service: Engineers avaliable to service overseas

Qualification: CE, ISO9001-2008

Munual folding case sealer to suit different case sizes

FXJ series case sealer is primarily applicable to the carton packaging and sealing. It can be operated individually or used in the production line. It is extensive used on electrical machinery, textiles, food, retail, pharmacy and chemical industries. With the use of the sealing tape, it is economic, high efficiency and easy to adjust. It can seal the carton by up and down direction at one time. It can improve their product image more adopting with word printed sealing tapes.

Specification:

Model	FXJ-6050B
Electrical Power	AC110-220V/60-50Hz
Total Power	180W
Conveyor Speed	15.7m/min (4-6cartons per min)
Style	top and bottom sealing
Tape width	48-60mm
Tape Length	≥150mm
Max Carton Width	500mm
Max Carton length	600mm
Air Pressure	2/3
Machine Size	960×850×1270mm
Gross Weight	180kg
